PE PP PET Plastic Film Shredder, High Efficiency Monofilament Film Shredder Machine 1000-2000KG Per Hour,Waste PP Raffia Yarns Shredder Machine Blade Wear Resistance

Features

High efficiency durable PP raffia shredder ,PP yarns shredder agro films shredder machine.
This rotary design machine is specially for soft materials cutting & crushing. It can be working as a crusher machine when install sieve mesh also it can be working as a pre shredder when it take off the sieve mesh. The machine is cutting like high speed rotatin scissors,so very power saving and high working efficiency.
Contact Us
-+
ADD to Quote

Product Details


The performance and features of the Crushers


  1. The conveyor belt automatically feeds materials into the pressure roller, making the feeding more uniform, avoiding the entanglement of film materials, and cutting long-sized materials into short-sized ones.

  2. Inside the crusher, there is a rotating tool. The tool has undergone special treatment and can break soft materials into small pieces in a short time. The blade can be reground to enhance durability.

  3. The size of the material to be cut can be adjusted. The entire set of equipment has a high degree of automation. Only one employee is needed to operate the entire process, which saves labor costs and has a high production efficiency.

The Application of Crushers


The crusher has a wide range of applications and is suitable for recycling and processing PP/PE waste plastic films, PP/PE plastic waste mixtures, waste PP cement bags, space bags, domestic waste plastics, waste agricultural greenhouse films, industrial packaging films, shopping bags, etc.


Product parameters


Model800F1200F
1600F2400F
Fixed Blade length400mm600mm800mm1200mm
Fixed Blade qty2222
Rotary blade qty8688
Cutting motor7.5kw18.5kw
22kw
22kw+22kw
Conveying motor1.5kw2.3kw3kw4kw
Input Conveyor belt size

1400*330mm

3000*520mm

3000*720mm

3000*1100mm

Sieve mesh adjustable range3mm-50mm3mm-140mm3mm-200mm3mm-200mm
work capacity (base on cut into10mm size)

100-150kg/h


250-350kg/h



450-650kg/h


800-1000kg/h

machine size (mm)

1350*1000*1100

1550*1450*1600

1550*1650*1700

2200*2043*1770

machine weight (kg)800
180023003500


Model 800C1200C1600C2400C
Fixed Blade length400mm600mm800mm1200mm
Fixed Blade qty2222
Rotary blade qty8688
Cutting motor7.5kw18.5kw22kw22kw+22kw
Conveying motor1.5kw2.3kw3kw4kw
input Conveyor belt size1400*330mm3000*520mm3000*720mm3000*1100mm
meshnonenonenonenone
work capacity400-500kg/h1000-1300kg/h2000-2500kg/h3000-5000kg /h
machine size (mm)1350*1000*11001550*1450*16001550*1650*17002200*2043*1770
machine weight (kg)800180023003500
Note

The machine can be used for multiple purposes and can work with or without a screen.

We support customized products for our customers. We can adjust our products according to your needs.

Crush and cut the material samples

We can adjust our machines according to your materials and dimensions


FAQ

What are the main products/services of our company?

  • Our company is a factory of soft material crushers,It can crush various materials such as wool, palm silk, waste plastic bags, various fibers, greenhouse films, all kinds of used clothes, car interiors, shoes and socks, fishing nets, cord fabrics, etc.

  • We support customized services. Customers can customize machines according to their own needs.

  • Our company supports the service of trial operation with supplied materials. We can conduct a trial operation based on the materials you have. You can purchase our machines only after you are satisfied.


Payment terms

  • We support various forms of payment such as TT and letter of credit.

  • Pay a 30% deposit to start production and settle the balance before shipment.


What are our advantages?

  • We are a factory, with a price advantage and the ability to customize at the same time.

  • We have over 20 years of production experience and possess stable technology and excellent quality. Have independent patents.

  • We are a factory, with a price advantage and the ability to customize at the same time.

  • We have over twenty years of production experience and possess stable technology and excellent quality. Have independent patents.

  • We support your visit to our factory for on-site machine testing. Meanwhile, we can also provide video and written guidance to assist you in installing and using the machine. We also support sending our technical engineers overseas to assist you in debugging the machine.
