After crushing, rain clothing material can be recycled and made into various new products. For example, they can be processed into recycled plastic particles that can be used to produce new plastic items, such as toys, containers, or even new raincoats. In addition, the crushed rain cloth can also be used as a filling material for making pillows, mattresses or other household items. In some cases, these materials can also be used to pave roads or as insulation in the construction industry. In this way, the crushing of rain clothing not only reduces the burden on landfills, but also provides a new way to recycle resources.
Product Parameters (1)
| Type parameter | 800F model | 1200Fmodel | 1600Fmodel |
1 | Shearing machine | 8P7.5kw | 8P18.5kw | 8P22kw |
2 | Conveyer motor | 4P1.5kw | 4P2.2kwVariable frequency motor | 4P3.0kwVariable frequency motor |
3 | Reduction type number | 100# | 120# | 125# |
4 | Reducer speed ratio | 31：1 | 31：1 | 31：1 |
5 | Shear motor cover Belt pulley | Φ140 | Φ160 | Φ180 |
6 | Moving cutter head | Φ300*400长 | Φ400*600长 | Φ500*800长 |
7 | Distribution box | Power distribution box | Independent electrical cabinet | Independent electrical cabinet |
8 | Input tape | 1400*330mm | 3000*520mm | 3000*720mm |
9 | Output tape | 3.0 Fan/conveyor belt | 4.0kw Fan/conveyor belt | 7.5kw Fan/conveyor belt |
10 | Moving cutter | Alloy tool steel 8 pieces *400 | Alloy tool steel 6 pieces*600 | Alloy tool steel 8 pieces*800 |
11 | Stationary knife | Alloy tool steel 2 pieces*400 | Alloy tool steel 2 pieces*600 | Alloy tool steel 2 pieces*800 |
12 | Machine size | 1350*1000*1100 | 1550*1450*1600 | 1550*1650*1700 |
13 | Cutting size | 10mm | 10mm | 10mm |
14 | Work capacity | 100-150kg/h | 250-350kg/h | 450-650kg/h |
15 | weight | 800kg | 1800kg | 2300kg |
Product Parameters（2）
| Type parameter | 2400F model | 2400F H model | 3200F model |
1 | Shearing machine | 8P 22kw *2 sets | 8P 30kw*2sets or 37kw*2 sets | 8P 55kw*2sets or 75kw*2 sets |
2 | Conveyer motor | 4P4.0kwVariable frequency motor | 4P4.0kwVariable frequency motor | 4P5.5kw Variable frequency motor |
3 | Reduction type number | 135# | 135# | 135# |
4 | Reducer speed ratio | 31：1 | 31：1 | 31：1 |
5 | Shear motor cover Belt pulley | Φ180 | Φ180 | φ220 |
6 | Moving cutter head | Φ600*1200 length | Φ800*1200 length | φ1000*1600 length |
7 | Distribution box | Independent electrical cabinet | Independent electrical cabinet | Independent electrical cabinet |
8 | Input tape | 3000*1100mm | 5000*1100mm | 5000*1500mm |
9 | Output tape | 11kwFan/conveyor belt | 11kw Fan/conveyor belt | 11kw Fan/conveyor belt |
10 | Moving cutter | Alloy tool steel 8 pieces*1200 | Alloy tool steel 16 pieces*600 | Alloy tool steel 32 pieces*400 |
11 | Stationary knife | Alloy tool steel 2*1200 | Alloy tool steel 4*600 | Alloy tool steel 4*400 |
12 | Machine size | 2200*2043*1770 | 2280*2200*2000 | 2350*3300*2400 |
13 | Cutting size | 10mm | 10mm | 10mm |
14 | Work capacity | 800-1000kg/h | 1000-1200kg/h | 2000kg/h |
15 | weight | 3500kg | 5100kg | 10500kg |
Standard: Main engine + conveyor belt Random gift: a set of fragile bearings, a set of triangle belts, a set of special toolbox |
Note:
1. Different cutting sizes of materials are different. There will be changes in output, and there will be changes in technical parameters. Need detailed communication.
2. About machine size. Only the dimensions of the machine are indicated in the specification sheet. Conveyor belt size is 3 meters, can also be customized according to customer requirements.
